Sheet 1 of 2
Assembly & Bill of Materials
Exploded assembly layout illustrating captured swivel interfaces, track tolerances, and hardware specifications for 3D printing and hardware fitment.
- Drafting Standard: ANSI / ASME Y14.5
- Primary Process: FDM Additive
- Critical Tolerance: ±0.15 mm
